Spesifikasi

Kecepatan Cetak

• High Speed Draft:
  • 10 cpi: 347 cps.
  • 12 cpi: 357 cps.
  • 15 cpi: 390 cps.
• Draft:
  • 10 cpi: 260 cps.
  • 12 cpi: 312 cps.
  • 15 cpi: 223 cps.
• NLQ (Near Letter Quality):
  • 10 cpi: 65 cps.
  • 12 cpi: 78 cps.
  • 15 cpi: 55 cps.

Fitur Cetak

• Print Method: Impact dot matrix (9-pin).
• Print Direction: Bi-directional dengan logic seeking.
• Character Sets: PC437, PC850, PC860, PC861, PC863, PC865, dan lainnya.
• Barcode Support: EAN-13, EAN-8, UPC-A, UPC-E, Code 39, Code 128, dan lainnya.

Keandalan

• Printhead Life: Sekitar 400 juta ketukan/pin.
• Mean Time Between Failure (MTBF): 10.000 POH (25% duty cycle).
• Mean Print Volume Between Failure (MVBF): 20 juta baris (kecuali printhead).

Konektivitas

• Standard Interfaces:
  • Bi-directional Parallel (IEEE-1284).
  • USB 2.0 Full-Speed.
  • Serial.

Media Kertas

• Cut Sheet (Single/Multi-part):
  • Panjang: 100 – 364 mm.
  • Lebar: 100 – 257 mm.
  • Ketebalan: 0.065 – 0.39 mm.
• Continuous Paper:
  • Panjang: 101.6 – 558.8 mm.
  • Lebar: 101.6 – 254.0 mm.
• Envelope: No.6 dan No.10.
• Roll Paper: Lebar 216 mm.

Dimensi & Berat

• Ukuran: 362 x 275 x 154 mm.
• Berat: Sekitar 4.1 kg.

Konsumsi Daya

• Ribbon Cartridge:
  • Fabric Ribbon Cartridge (Black) – C13S015632.
  • Ribbon Life: Sekitar 4 juta karakter (Draft 10 cpi).

Dukungan Sistem Operasi

• Windows: 2000, XP, Vista, 7, 8, 8.1, 10.

Lingkungan Operasi

• Suhu: 5 – 35°C.
• Kelembapan: 10 – 80% RH.
