Form Factor
ATX

Watts
550W

PFC
Active PFC

ErP 2014 Lot 3
Yes

Operating Temperature
0-40°C

Input Frequency
50-60Hz

ATX 24 Pin Connectors
1

Power Good Signal
100 – 150 ms

Warranty
5 Years

EPS 4+4 Pin Connectors
2

Fan Size
120mm

MTBF
>100,000 Hours

Category
500 to 750W

80 PLUS Rating
80 PLUS Bronze

Modular
Non Modular

Fan Bearing
HDB

80 Plus
Bronze

Input Voltage
100-240V

PCI-e 6+2 Pin Connectors
2

SATA Connectors
6

Peripheral 4 Pin Connectors
3

Protections
OVP

Series
MWE Bronze Series

Protections
OPP

Protections
SCP

Dimensions (L x W x H)
140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch

Protections
UVP

Protections
OTP

Hold Up Time
>16ms

Input Current
8-4A

Regulatory
CCC

Regulatory
CE

ATX Version
ATX 12V Ver. 3.1

Efficiency
>85% @ Typical Load

Regulatory
RCM

Regulatory
EAC

Regulatory
cTUVus

Regulatory
FCC

Regulatory
BSMI

Regulatory
TUV

Regulatory
UKCA

Regulatory
RoHS2.0 / BIS

Regulatory
KC (based on region’s request.)
