Spesifikasi

CPU

• AMD Socket AM5, mendukung prosesor AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series

Chipset

• AMD A620

Memori

• Mendukung DDR5 hingga 8000(OC) MT/s
• 4 x DDR5 DIMM sockets, hingga 256 GB (64 GB per slot)
• Arsitektur dual channel
• Dukungan AMD EXPO™ dan XMP untuk overclocking

Grafis Terintegrasi

• 1 x DisplayPort 1.4: resolusi maksimum 3840×2160@144 Hz
• 1 x HDMI 2.1: resolusi maksimum 4096×2160@60 Hz

Audio

• Realtek® Audio CODEC
• High Definition Audio, mendukung 2/4/5.1/7.1-channel

Jaringan

• Realtek® GbE LAN (1 Gbps/100 Mbps)

Slot Ekspansi

• 1 x PCI Express x16 (PCIe 4.0, tergantung CPU)
• 1 x PCI Express x1 (PCIe 3.0)

Penyimpanan

• 1 x M.2 (PCIe 4.0 x4/x2, tergantung CPU)
• 4 x SATA 6Gb/s
• Dukungan RAID 0, 1, dan 10 untuk NVMe SSD dan SATA

USB
CPU:

• 1 x USB 3.2 Gen 2 Type-A (merah)
• 1 x USB Type-C® (USB 3.2 Gen 1)
• 1 x USB 3.2 Gen 1

Chipset:

• 1 x USB Type-C® internal (USB 3.2 Gen 1)
• 3 x USB 3.2 Gen 1 (1 belakang, 2 internal)
• 4 x USB 2.0/1.1 (2 belakang, 2 internal)

Konektor Internal

• 1 x 24-pin ATX power
• 1 x 8-pin ATX 12V power
• 1 x CPU fan header, 2 x system fan header
• 1 x M.2 Socket 3
• 4 x SATA 6Gb/s
• 1 x USB Type-C® header (USB 3.2 Gen 1)
• 1 x USB 3.2 Gen 1 header
• 1 x USB 2.0/1.1 header
• 1 x RGB & 1 x Addressable LED header

Panel Belakang

• 1 x PS/2 keyboard/mouse
• 1 x USB Type-C® (USB 3.2 Gen 1)
• 1 x USB 3.2 Gen 2 Type-A (merah)
• 2 x USB 3.2 Gen 1
• 2 x USB 2.0/1.1
• 1 x HDMI, 1 x DisplayPort
• 1 x RJ-45 LAN
• 3 x Audio jacks

Form Factor

• Micro ATX, 24.4 cm x 24.4 cm
