Specifications
| Image | |
| Projection Technology | Texas Instruments DLP® |
| Panel Size | 0.55″ DMD |
| Native Resolution | XGA |
| Pixels | 1024 x 768 |
| Aspect Ratio | 4:3 |
| Contrast Ratio | 30000:1 |
| Brightness (Lumens) | 3800 |
| Light Source | UHP Lamp |
| Light Source Life Maximum Hours | 15000 |
| Maximum Supported Resolution | 1920 x 1200 |
| Horizontal Sync. Range (KHz) | 31 ~ 97 |
| Vertical Sync. Range (Hz) | 56 ~ 85 |
| Uniformity (%) | 80 |
| Optical | |
| Lens | 1.1x |
| Lens Zoom Adjustment | Manual |
| Optional Lenses | – |
| Image Offset (%) | 115 |
| Focal Length (mm) | 21.85 ~ 24.01 |
| F-Stop | 2.41 |
| Vertical Lens shift (%) | – |
| Horizontal Lens shift (%) | – |
| Keystone Adjustment | Manual |
| Vertical Keystone Correction | ± 40° |
| Horizontal Keystone Correction | – |
| Projection Factor | 1.94:1 ~ 2.16:1 |
| Projection Distance (Meters/Feet) | 11.2 ~ 11.9 / 3.9 ~ 39 |
| Optical Zoom | 1.1:1 |
| Digital Zoom Demagnification / Magnification | 0.8x ~ 2.0x |
| Focus Adjustment | Manual |
| Connectivity | |
| Inputs |
|
| Outputs |
|
| Other |
|
|---|---|
| Power | |
| Power Supply | 100 ~ 240 V AC; 50 ~ 60 Hz |
| Power Consumption Max (W) | 267 |
| Power Consumption Min. (W) | 210 |
| Power Consumption Network Standby (W) | – |
| Power Consumption Standby (W) | <0.5 |
| General | |
| Dimensions (W x H x D) (mm / in) | 236 x 313 x 107 / 9.3 x 12.4 x 4 |
| Product Weight (Kilograms/Pounds) | 2.6 / 5.7 |
| Fan Noise (dB) | 30 |
| Audio (W) | 3 |
| Operating Temperature (Celsius/Fahrenheit) | 5 ~ 40 / 41 ~ 104 |
| Operating Humidity (%) | 10 ~ 85 |
| Max Operating Altitude (meters / feet) | 3048 / 10000 |
| Storage Temperature (Celsius/Fahrenheit) | -10 ~ 60 / 14 ~ 140 |
| Storage Humidity (%) | 10 ~ 85 |
| Security | Kensington Security Slot™, PIN Code Lock & Timer |
| In the Box | VGA Cable, Power Cord, Remote Control (No Batteries) |
| Safety and Regulatory | CB, CE, EAC, cTUVus, CCC, FCC, UKCA, NOM, PSB, BIS |
| Environmental | WEEE, EU RoHS, China RoHS, CEL, CECP |
